DS-G13 Hot Air Hot Wedge Plastic Welding Machine
DS-G13 Hot Air Hot Wedge Plastic Welding Machine
1. This machine adopts advanced technology and has functions of hot air and hot wedge. Hot air and
hot wedge functions can be switched, easy to replace. It can meet various welding requirements of
TPU.PVC.PE. PVC mesh cloth, etc.
2. It adopts editable PLC control system, high-definition touch screen display, Chinese and English
system, can be programmed according to user requirements, microcomputer automatically controls
the whole machine, simple operation, stable action performance, and low failure rate.
3. Auto temperature control with warning device for the up limit temperature.
4. Auto compensation, auto micro back to reduce empty welding.
5. Double pedals control, the upper and lower pressing rollers and the rear dragging rollers can realize the independent drive of the motor, and the speed
differential function can be set to effectively prevent the shrinkage and wrinkling of the elastic fabric.
6. It could work up to 24 hours continuously.
7. The unique heating structure can reach up to 750 C for hot air, and 500 C for hot wedge, the temperature is automatically tracked and controlled by a
computer, and the accuracy can reach ±1C.
8. Super strong torsional dynamic design.
9.Blowing-in hot air is filtrated without any water and oil.
10. The hot wedge function is noiseless, energy-saving, environmentally friendly and smoke-free, with strong welding fastness, no wrinkles, and no bright
edges.
11. The equipment can set different parameters according to different welding materials, and automatically store them, which is convenient to call and
improve work efficiency.
12. The super wide hot welding space with worktable, the worktable can be dismantled, it is more suitable for the processing of medium, large and super
large tents, car covers, rubber boats, outdoor barracks, inflatable boats, inflatable bouncy trampoline, tarpaulin, banner and other products.
应用/Application
大型充气帐篷、充气船、橡皮艇、充气游泳池、气球、广告横幅、无缝缝制品和渔船等
Large inflatable tents, rubber boats, inflatable boats, inflatable swimming pools, balloons, banner, seamless sewing products, and
fishing boats, etc.
