SPCM-2P-4 Automaticweighing Fiber Filling Machine

SPCM-2P-4 Automaticweighing Fiber Filling Machine

Installation Requirements As Blew:

Air pressure required throughput after 1m2/min or more, if air supply pressure not lessthan 0.6 Mpa, and other equipment share the air supply, then required the air supplytube

less than 20 meters in length, pipe size 1.5 inches or more, need to add air intakehas no oil or water purifier. For example, it is recommended to use 7.5kw high pressureair pump

and 1.5m2 cubed air storage tank (which will prolong the service life of aircompressor).

The voltage requires that the line load power can carry 4KW above the voltage ofAC380V/50HZ (custom-izable AC220V/50HZ), and there must be ground wire before themachine is energized.
